| 2 channels driven, 20Hz - 20kHz, 8Ω |
120W |
| 2 channels driven, 1kHz, 4Ω |
200W |
| Harmonic distortion, 80% power, 8Ω at 1kHz |
0.002% |
| Number of inputs |
3 (RCA pairs) |
| Phono Inputs |
MM and MC |
| Frequency response |
20Hz - 20kHz ± 0.2dB |
| Signal/noise ratio (A-wtd, ref. 50W, 1V input) |
106dB |
| Supported Streaming media |
FLAC, WAV (LPCM), AAC, ALAC, AIFF,
DSD (up to 256), MP3, MP4, OGG, WMA
|
| Supported Streaming Bit depth |
16, 24, 32 |
| Supported Streaming sample rates (kHz) |
Up to 384 kHz |
| Gapless Playback |
Yes |
| Digital Audio Inputs |
1x HDMI eARC, 2x Coaxial (RCA), 2x Optical (Toslink) |
| Supported Digital input Bit depth |
16, 24 |
| Supported Digital input sample rates (kHz) |
Up to 192 kHz |
| Frequency response (filter 1) |
20Hz - 20kHz ± 0.2dB |
| Signal/noise ratio (A-wtd, ref. 50W, 0dBFS) |
110dB |
| Bluetooth Profile |
5.4; A2DP Sink/Source, AVRCP, BLE,
Snapdragon Sound, AAC, LE Audio, Auracast
|
| Bluetooth Transmitter Frequency and Power |
2,402 MHz to 2,480 MHz: <13dBm |
| Wi-Fi Network |
IEEE 8002.11 a/b/g/n/ac (2.4GHz/5GHz) |
| 2.4G Wi-Fi Transmitter Frequency Range and Power |
2400-2483.5 MHz (USA 11 Channels
, Europe and Others 13 Channels) <20dBm
|
| 5G Wi-Fi Transmitter Frequency Range and Power |
5150-5250 MHz <23dBm, 5250-5350
MHz & 5470-5725 MHz <20dBm, 5725-5850 MHz <14dBm
|
| Mains voltage |
100V or 110–120V or 220–240V, 50–60Hz |
| Power consumption (maximum) |
700W |
| Power consumption (standby) |
<0.5W |
| Dimensions W x D (including speaker terminals) x H (including feet) |
432 x 344 x 99mm |
| Weight (net) |
12 kg |
| Weight (packed) |
14 kg |
| Items |
Mains lead(s), Remote control with 2 x AAA batteries,
Measurement Microphone,
5m USB Cable,
Quick Start Guide, Important Safety Instruction
|
