Projection System
|
DLP
|
DMD size
|
0.47" ECD
|
Product Features
|
4K, HDR10 /HLG, 3D, RGBW, 98% Rec709, MEMC, 1.3x Zoom, 1D keystone, Vertical L/S, CinemaMaster Video+. CinemaMaster Audio+
|
Native Resolution
|
4K UHD (3840×2160)
|
Native Aspect Ratio
|
16:09
|
Brightness (ANSI lumens)
|
3000
|
Contrast Ratio (FOFO)
|
30,000:1
|
Selectable Aspect Ratio
|
16:9,4:3,Auto
|
Display Color
|
30-bit (1.07 billion colors)
|
Light Source
|
Lamp
|
Light Source Wattage
|
245W
|
Light Source Life
|
a. Normal 4000 hrs,b. ECO 10000 hrs,c. SmartEco 15000 hrs
|
Throw Ratio
|
1.13~1.47
|
Zoom Ratio
|
1.3x
|
Lens
|
F/# = 1.9 - 2.47, f = 12 - 15.6 mm
|
Projection Offset (Full-Height)
|
100%
|
Keystone Adjustment
|
1D, (Auto) Vertical ± 30 degrees
|
Lens Shift Vertical
|
10%
|
ANSI Uniformity (Min.)
|
-45%
|
Clear Image Size
|
40"~200"
|
Image Size
|
30"~300"
|
Picture Modes
|
3D,Bright,Cinema,HDR,HLG,Living Room,Silence,Sports,User
|
Color Wheel Segment (Lamp)
|
8 segment (RGBWRGBW)
|
Color Wheel Speed
|
100Hz,120Hz,3D (120Hz),96Hz
|
Rec. 709 Coverage
|
98%
|
Input Lag
|
83.34ms (1080p@60Hz),83.34ms (4K@60Hz)
|
Resolution Support
|
VGA (640 x 480) to 4K UHD (3840 x 2160)
|
Horizontal Frequency
|
15K~135KHz
|
Vertical Scan Rate
|
23~120Hz
|
HDTV Compatibility
|
1080i,1080p,2160p,480i,480p,576i,576p,720p
|
3D Compatibility
|
Frame Packing (Blu-ray),Side by Side (Streaming),Top Bottom (Streaming)
|
HDMI in
|
(x3),HDMI-1 (2.0b/HDCP2.2),HDMI-2 (2.0b/HDCP2.2),HDMI-3 (2.0/HDCP2.2),HDMI-Internal (2.0b/HDCP2.2)
|
USB Type A
|
(x2),USB Type A-1 (3.0/Power Supply1.5A),USB Type A-2 (3.0/Power Supply1.0A/Reader),USB Type A-3 (2.0/Power Supply2.5A)
|
USB Type Mini B
|
(x1),USB Type Mini B-1(service)
|
RS232 in (DB-9pin)
|
(x1)
|
DC 12V Trigger (3.5mm Jack)
|
(x1)
|
Speaker
|
(x2),5W Chamber
|
Audio out (3.5mm Mini Jack)
|
(x1)
|
Audio EQ
|
Yes
|
Audio L/R Switch
|
Yes
|
HDMI Audio Return
|
Yes, ARC, 2 channel
|
Power Supply
|
AC 100 to 240 V, 50/60 Hz
|
Typical Power Consumption (110V)
|
330W
|
Stand-by Power Consumption
|
<0.5W
|
Acoustic Noise (Typ./Eco.)(dB)
|
30/28
|
Operating Temperature
|
0~40℃
|
Android TV dongle
|
(Standard),QS01
|
Remote Control w/ Battery
|
RCI067,RCV017
|
Power Cord (by region)
|
(Standard),x1 (3.0M)
|
3D Glasses
|
(Optional),DGD5
|
Quick Start Guide
|
(x1) 21L
|
Warranty Card (by region)
|
Yes
|
Lens cover
|
Yes
|
Universal Ceiling Mount
|
(Optional),CMG3
|
OSD Language
|
28L
|
Built-in OS
|
Yes, Android 9.0
|
ROM/RAM
|
16GB/2GB
|
Bluetooth
|
Yes, Bluetooth 4.2
|
Wi-Fi Standard
|
802.11 a/b/g/n/ac (2.4G/5G)
|
Dimensions (WxHxD) (mm)
|
380 x 127 x 263
|
Dimensions (WxHXD) (inch)
|
14.9 x 4.99 x 10.35
|
Net Weight (kg)
|
4.2
|
Net Weight (lb)
|
9.25
|
