| Amplification |
| Number of Power Amp Channels |
13 |
| Power Output (8 ohm, 2ch driven) |
150W per channel (20Hz to 20kHz, 0.05% THD) |
| Power Output (6 ohm, 2ch driven) |
190W per channel (1kHz, 0.7% THD) |
| Power Output (6 ohm, 1ch driven) |
210W per channel (1kHz, 10% THD) |
| Multichannel Pre-Amp Outputs |
15.4 channels |
| Max Speaker Configuration |
9.4.4 / 7.4.6 |
| Number of Speaker Terminals |
15 |
| Subwoofer Outputs |
4 (independent) |
| Surround Sound Formats |
| Dolby |
Dolby Atmos, Dolby TrueHD, Dolby Surround, Dolby Atmos Height Virtualization, Dolby Atmos Music |
| DTS |
DTS:X, DTS:X Pro, DTS HD Master, DTS Neural:X, DTS Virtual:X |
| IMAX Enhanced |
Yes |
| AURO-3D |
Yes |
| 360 Reality Audio / MPEG-H |
Yes / Yes |
| Audio Processing |
| DAC |
9 x audiophile-grade 2-channel DAC chips |
| Hi-Res Audio |
FLAC, ALAC, WAV up to 192kHz/24-bit; DSD 2.8/5.6MHz |
| Room Calibration |
Audyssey MultEQ XT32 (included) |
| Dirac Live |
Upgradable via license purchase |
| Audyssey Dynamic EQ / Dynamic Volume |
Yes / Yes |
| Front Display |
2-Line Fluorescent (FLD) |
| HDMI and Video |
| HDMI Inputs |
7 (all HDMI 2.1 / 8K capable) |
| HDMI Outputs |
3 (including 1 x eARC) |
| HDCP Version |
2.3 |
| 8K Pass-Through / Upscaling |
Yes / Yes (8K/60Hz) |
| 4K/120Hz |
Yes |
| HDR Support |
HDR10, HDR10+, Dynamic HDR, HLG, Dolby Vision |
| Gaming Features |
VRR, ALLM, Quick Frame Transport (QFT) |
| Audio Return Channel |
ARC and eARC |
| Inputs and Outputs |
| Analogue Inputs |
7 + 1 (including Phono MM) |
| Phono Input (MM) |
Yes |
| Digital Inputs |
2 x Optical, 2 x Coaxial |
| USB (Front) |
Yes |
| Multi-Room Analogue Output |
2 |
| Ethernet |
Yes |
| Network and Streaming |
| Wi-Fi |
Yes |
| Bluetooth |
Yes |
| HEOS Built-In |
Yes (multi-room / multi-zone) |
| AirPlay 2 |
Yes |
| Spotify Connect |
Yes |
| Voice Assistants |
Amazon Alexa, Google Assistant, Apple Siri |
| Control and Integration |
| Remote Control |
RC-1261 |
| Multi-Room Zones |
3 |
| IP Control / RS232 / Web Control |
Yes / Yes / Yes |
| Control4 SDDP Certified |
Yes |
| 12V Trigger Outputs |
3 |
| IR In / Out |
Yes / Yes |
| Power |
| Power Consumption (Max) |
900W |
| Power Consumption (No Signal, ECO off) |
125W |
| Standby Consumption |
0.1W |
| Network Standby Consumption |
Less than 2.0W |
| General |
| Dimensions without antenna (W x D x H) |
434 x 472 x 195mm |
| Dimensions with horizontal antenna (W x D x H) |
434 x 482 x 195mm |
| Dimensions with vertical antenna (W x D x H) |
434 x 482 x 259mm |
| Weight |
23.6kg |
| Available Finishes |
Black / Silver |
| Country of Manufacture |
Japan (Shirakawa Audio Works) |
