| Amplifier Performance |
| Power Output, 2, 4 and 8 ohms |
200 W per channel |
| Rated Power Band |
20 Hz - 20 kHz |
| Dynamic Headroom |
3.1 dB |
| Total Harmonic Distortion |
0.005% |
| Frequency Response |
20 Hz - 20 kHz (+0, -0.5 dB) |
| Frequency Response, Extended |
10 Hz - 100 kHz (+0, -3 dB) |
| Damping Factor |
Greater than 40 |
| Output Type |
Paired McIntosh Autoformers |
| Maximum Output, Unbalanced |
8 V |
| Signal to Noise and Sensitivity |
| S/N Ratio, High Level |
95 dB |
| S/N Ratio, Phono MM |
82 dB |
| S/N Ratio, Phono MC |
80 dB |
| S/N Ratio, Power Amp Input |
113 dB |
| Input Sensitivity, Balanced |
0.5 V |
| Input Sensitivity, Unbalanced |
0.25 V |
| Input Sensitivity, Phono MM |
2.5 mV |
| Input Sensitivity, Phono MC |
0.25 mV |
| Input Sensitivity, Power Amp |
1.4 V |
| Input Impedance |
20 kilohms balanced and unbalanced |
| Analogue Inputs and Outputs |
| Balanced Inputs |
1 XLR |
| Unbalanced Inputs |
6, gold-plated solid brass |
| Moving Magnet Phono Input |
1, fixed loading |
| Moving Coil Phono Input |
1, adjustable loading |
| Unbalanced Variable Outputs |
2 |
| Unbalanced Fixed Output |
1 |
| Headphone Output |
1/4 inch, High Drive with HXD |
| Speaker Binding Posts |
Gold-plated |
| Digital Inputs and Conversion |
| Digital Module |
DA2, standard and upgradeable |
| Digital to Analogue Converter |
8-channel, 32-bit/384 kHz PCM and DSD, quad balanced |
| Coaxial Inputs |
2, 24-bit/44.1 kHz to 192 kHz |
| Optical Inputs |
2, 24-bit/44.1 kHz to 192 kHz |
| USB Input |
1, PCM 32-bit up to 384 kHz, DSD64 to DSD512, DXD 352.8 and 384 kHz |
| MCT Input |
1, 16-bit/44.1 kHz CD or DSD64 SACD |
| HDMI Input |
1 ARC, audio only, multichannel converted to 2-channel |
| Total Inputs |
15 analogue and digital |
| Roon |
Roon Tested |
| Control and Protection |
| Tone Control |
Discrete 5-band analogue, ±12 dB in 2 dB steps |
| Tone Control Frequencies |
30 Hz, 250 Hz, 500 Hz, 2 kHz and 10 kHz |
| Input Assign and Level Match |
Yes, with custom input names |
| Home Theater PassThru |
Yes |
| Power Guard |
Yes |
| Sentry Monitor |
Yes, fuseless with automatic reset |
| Output Meters |
Yes, McIntosh Blue |
| RS232 Control Input |
Yes |
| Power Control |
1 main output, 2 trigger outputs |
| Rear Panel Data Ports |
4 |
| Rear Panel IR Sensor Inputs |
Yes |
| General |
| Type |
Solid state |
| Finish |
Polished stainless steel chassis, black glass front panel with LED lighting, aluminium end caps |
| Dimensions (W x H x D) |
445 x 194 x 476 mm |
| Standby Power Consumption |
Less than 0.25 W |
| Net Weight |
34.1 kg |
| Shipping Weight |
42.3 kg |
